• Features: Wedge Suspension kit Type A with Eyebolt nuts and split pin
  • Material: Galvanised Steel
  • Marking: According to standard, Size and CE mark
  • Finish: Galvanised
  • Standard: EN 13411-7
    Wedge socket 3050 type A - for lifting - measurements
    Wedge Socket 3050 type A - for lifting - measurements
    Select a row from the table below, then click the add to quote button
    Part Code Rope diameter
    mm
    Thread L
    mm
    Weight
    kg
    -- 6-8 M12 320 0,75
    -- 9-11 M16 320 1,6
    -- 12-14 M20 400 3,2
    -- 15-17 M24 450 5,3
    -- 18-20 M27 500 8,1
