General: MINIFOR™ hoists are used with a Maxiflex wire rope. They can be used to lift or pull objects over great distances depending on the wire rope length. They are suitable for use in numerous configurations. They are operated through a pushbutton control. Optionally, the MINIFOR™ hoist can be equipped with a wire rope reeling device or a wireless remote control.
- Capacity 100 kg, 300 kg or 500 kg.
- Quick installation.
- Easy to use, light-weight, robust, powerful.
- Available as single phase and three phase model.
- Excellent capacity / weight ratio.
- Unlimited wire rope travel.
- Pendant control (up/down/emergency stop) 2,5 m.
- Aluminium alloy design.
- Swivelling suspension hook.
- Protection: IP55 (Control: IP65).
- Upper and lower limit switches.
- Alternatively with cable reeling device (max. 40 m), wireless remote control, set of sheave blocks.

Options:
- Special sleave block kits are available for all models (max. 980 kg). They enable doubling the capacity half the working speed.
- Extension power supply and control cabel per m.
- Radio remote control.
- Wire rope 10-100 m in 10 m. length interval. Other lengths on request.
- Do only use original Minifor steel wire rope.
- Metal storage box.
- Wire rope reeler.

  • Marking: Load capacity, serial number and CE marking.
  • Note: Excl. wire (to be ordered separately).
Minifor TR10
TR30 with blockkit
Minifor TR50
TR10 TR30_dwg TR30S-TR50_dwg
Select a row from the table below, then click the add to quote button
Art No WLL
Ton
A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G (mm) H (mm) I (mm) J (mm) K (mm) L (mm) M (mm) N (mm) O (mm) P (mm) Q (mm) Type WLL sheaved (ton) Speed direct (m/min) Speed sheaved (m/min) Weight
kg
CAD
16.21042789 0.1 427 20 140 631 209 112 20 20 324 356 114 15 TR10 0,2 15 7,5 20
16.21042889 0.3 427 20 140 631 209 112 20 20 324 356 114 15 TR30 0,6 5 2,5 20
16.21042989 0.3 430 20 212 642 365 224 194 90 20 20 347 492 302 15 160 68 35 TR30S 0,6 13 6,5 33
16.21044849 0.5 430 20 212 642 365 224 194 90 20 20 347 492 302 15 160 68 35 TR50 0,95 7 3,5 33
Wire rope ø 6,5 mm

Download CAD

Description

Get CAD
Download
Type
Dimensions
Power supply*


Wire rope reeler


Radio
Weight without wire rope

LxWxD mm
Single phase
115 Volt
Single phase
230 Volt

3 phase
400 Volt

20 m
27 m
40 m
control
kg
TR10
355x420x180

21




TR30
355x420x180

21,5




TR30S
495x425x225



32






TR50
495x425x225



32







* Power supply 50 and 60Hz
