Crosby

General:
- For Flemish eye wire rope splicing.
- Designed for low temperature toughness.
- Resists cracking when swaged (equals or exceeds stainless steel sleeves).
- Special processed low carbon steel.
- “COLD TUFF”® for better swageability.
- Can be stamped for identification after swaging without concern for fractures when following these directions.
- Use round corner stamps to a maximum depth of 0.015 in. (1/64). The area for stamping should be on the side of the sleeve in the plane of the sling eye, and no less than 0.250 in. (1/4) from either end of the sleeve.
- Standard Steel Sleeve terminations have efficiency ratings as follows based on the catalog strength of wire rope.

      Product Image 1
      Product Image 2
      Select a row from the table below, then click the add to quote button
      Part Code Rope diameter Ferrule size
      mm
      Size
      mm
      S-505 Termination efficiency type of wire rope IWRC S-505 Termination efficiency type of wire rope FC CAD
      04C0380 6-7 6-7 6-7 96% 93% -
      04C0390 8 8 8 96% 93% -
      04C0400 10 10 10 96% 93% -
      04C0410 11 11 11 96% 93% -
      04C0420 13 13 13 96% 93% -
      04C0430 14 14 14 96% 93% -
      04C0440 16 16 16 96% 93% -
      04C0450 19 19 19 96% 93% -
      04C0460 22 22 22 96% 93% -
      04C0470 26 26 26 96% 93% -
      04C0480 28 28 28 92% 89% -
      04C0490 32 32 32 92% 89% -
      04C0500 35 35 35 92% 89% -
      04C0510 38 38 38 92% 89% -
      04C0515 44 44 44 92% 89% -
      04C0520 52 52 52 92% 89% -
