Hydraulic Tirfor™ machines are portable motorised hoists used with maxiflex wire rope. They can be used to lift, pull and position loads over great distances depending on the wire rope length. They are suitable for use in numerous configurations and are the ideal solution for use in professional applications; they are operated by an hydraulic cylinder powered by either an electrical power pack or a petrol motor power pack Option: the load capacity of the Tirfor® system can be increased by using sheave blocks.

  • Low weight-quick installation
  • No limitation in terms of wire rope length
  • Easy to use, light-weight, robust, powerful, increased wear-resistance
  • Increase load capacity with sheave blocks
  • Overload protection
  • Precise load positioning within millimetres
      TU16H Hydraulic Tirfor
      TU16H_dwg
      Select a row from the table below, then click the add to quote button
      Part Code WLL
      kg
      Ø wire rope
      mm
      Effort to control lever* Forward
      kg
      Effort to control lever* Reverse
      kg
      Rope travel* Forward
      mm
      Rope travel* Reverse
      mm
      A
      mm
      B
      mm
      C
      mm
      D
      mm
      E
      mm
      F
      mm
      G
      mm
      H
      mm
      I
      mm
      J
      mm
      K
      mm
      L
      mm
      M
      mm
      Weight
      kg
      -- 1 600 11,5 54 20 56 70 38 36 48 800 646 483 86 400 236 31 78 144 160 30
      Nominal WLL.
