Powertex

Design: Forged according to U.S. specification RR-C-271D Type IVA, Grade A, Class 2. Supplied with head-bolt with nut and cotter pin.

  • Material: Forged alloy steel. Head-bolt in alloy steel. Not to be heat-treated.
  • Marking: WLL, CE, size, grade, charge number and manufacturer ID.
  • Finish: Hot dip galvanized.
  • Safety factor: 6:1.
  • Grade: 6
1232_lom_225mm
128716
Select a row from the table below, then click the add to quote button
Art No Code WLL
Ton
Pin Ø d1 (mm) Nominal Size a* (mm) c* (mm) D (mm) D2 (mm) e (mm) H1 (mm) Weight
kg
05A4010 1,232 0.5 8 1/4 13 29 6,5 17,5 20 42,5 0.05
05A4020 1,233 0.75 9,5 5/16 13,5 31 8 21 21,5 47 0.1
05A4040 1,234 1 11,2 3/8 17 37 10 25 26,2 56,5 0.15
05A4030 1,235 1.5 12,7 7/16 18,5 43 11,3 27 29,5 63,5 0.22
05A4050 1,236 2 15,8 1/2 20,6 48 12,7 30,5 33,3 75,5 0.36
05A4060 1,237 3.25 18,8 5/8 27 60 16 40 43 92 0.76
05A4070 1,238 4.75 22 3/4 32 72 19 48 51 106 1.2
05A4080 1,239 6.5 25 7/8 37 85 22 54 58 120 1.8
05A4090 1,240 8.5 28 1 43,5 96 26,5 60 68,5 135 2.6
05A4100 1,241 9.5 32 1-1/8 48 109 29 68 75 143 3.8
05A4110 1,242 12 35 1-1/4 53 121 32 76 84 164 5.3
05A4120 1,243 13.5 38 1-3/8 59 134 35 84 94 182 7.2
05A4130 1,244 17 42 1-1/2 62 149 38 92 99 195 9.4
05A4140 1,245 25 50 1-3/4 75 178 45 106 128 224 15
05A4150 1,246 35 56 2 84 197 52 122 148 248 24
05A4160 1,247 55 70 2-1/2 107 270 66 145 186 302 45
05A4170 1,248 85 80 3 130 325 76 165 205 395 70
*Tolerance: +/- 5%
