Crosby

Design: Hook-eye. End fittings are quenched and tempered, bodies heat treated by normalizing.

Proof: 2 x WLL.


Standard: According to Federal Specifications FF-T-791b.
Note! Turnbuckles recommended for straight or in-line pull only.

  • Marking: Logo, size and type.
  • Finish: Hot dipped galvanized.
  • Safety factor: 5:1.
Crosby HG225
Select a row from the table below, then click the add to quote button
WLL
Ton
Thread dia. & take up (mm) Thread dia. & take up (inch) A (mm) D (mm) E closed F (mm) J open K closed M open N closed R (mm) S (mm) X closed BB (mm) Weight
kg
CAD
0.18 6,35 x 102 1/4 x 4 6,35 11,2 42,3 32,3 296 195 312 211 20,6 8,64 44,6 103 0.14
0.32 7,94 x 114 5/16 x 4-1/2 7,94 12,7 50,7 38,1 343 229 363 248 24,1 11,2 55,8 116 0.23
0.45 9,53 x 152 3/8 x 6 9,53 14,2 57,8 44,7 434 282 458 306 28,7 13,5 62,9 155 0.36
0.68 12,7 x 152 1/2 x 6 12,7 16,5 89,7 57,9 497 345 528 376 35,8 18,0 90,4 153 0.82
0.68 12,7 x 305 1/2 x 12 12,7 16,5 89,2 57,9 809 504 840 535 35,8 18,0 89,9 314 1.22
1.02 15,9 x 152 5/8 x 6 15,9 22,9 108 71,4 536 384 574 422 45,7 22,4 110 153 1.35
1.02 15,9 x 305 5/8 x 12 15,9 22,9 107 71,4 850 545 888 583 45,7 22,4 110 315 1.97
1.36 19,1 x 152 3/4 x 6 19,1 24,9 129 84,6 574 422 621 469 53,1 25,4 130 156 1.91
1.36 19,1 x 305 3/4 x 12 19,1 24,9 128 84,6 889 584 936 631 53,1 25,4 129 320 2.96
1.36 19,1 x 457 3/4 x 18 19,1 24,9 129 84,6 1,194 737 1,241 784 53,1 25,4 130 471 3.74
1.81 22,2 x 305 7/8 x 12 22,2 28,7 148 96,0 917 612 971 666 60,5 31,8 147 309 4.24
2.27 25,4 x 305 1 x 12 25,4 31,8 167 108 956 652 1,018 713 76,2 36,3 165 309 6.29
